E-DAT Industry terminal rail TS35 and RJ45 field jack insert Cat.6 Class EA, T568A
Connection unit for mounting on mounting rail TH35 according to DIN EN 60715 in electrical distributors for house and industrial installation.
Protection class
- when installed as a device of protection class I, the equipotential bonding takes place via a switchable, integrated equipotential bonding spring directly on the mounting rail, which is to be connected to the building equipotential bonding using appropriate contacting terminals
Suitable for
- suitable for 10 GBit Ethernet (IEEE 802.3an), remote powering (PoE, PoE plus, UPoE) and HDBaseT
Installation
- installation-friendly connection of the 2 to 4-pair data line AWG 24/1 - 22/1 and stranded wire with 7-wire CU strand AWG 26/7 to BTR 8-way IDC insulation displacement terminals
the construction width of 1TE enables the installation of up to 12 devices in a standard electrical distributon
Variants
- wiring according to T568A, T568B or PROFINET
