M12 jack, D-coded, IP67, Cat. 5, Ø 6-9.7 mm,
field assembly, straight

Description
  • 4-pole jack for field assembly Cat.5e
  • M12 connector following to DIN EN 61076-2-101:2012
  • suitable for 100 MBit Fast Ethernet as per IEEE 802.3an
  • AWG 26/1 to 22/1, AWG 26/7 to 22/7 can be connected
  • solid copper wire diameter 0.41 to 0.64 mm
  • stranded copper wire diameter 0.48 to 0.76 mm
  • wire diameter with isolation up to 1.6 mm
  • cable jacket from 6.0 to 9.7 mm
  • jack consists of only two parts
  • easy assembly without special tools
  • industry-compatible zinc die-cast housing
  • suitable for applications in the railway industry according to data sheet
Technical Data
General Data
E2
Jack
shielded
Copper
49 mm
16.8 mm
16.8 mm
1.929 in.
0.661 in.
0.661 in.
yes
on housing
Transmission characteristics
5e
5e
yes
IEEE 802.3af
IEEE 802.3at
Connections/interfaces
IDC-connection
M12-jack
D-coded
1
1
4
4
AWG 26/1 - AWG 22/1
0,128 - 0,324 mm²
0,409 - 0,643 mm
0,016 - 0,025 in.
AWG 26/7 - AWG 22/7
0,141 - 0,355 mm²
0,483 - 0,762 mm
0,019 - 0,03 in.
0.85 mm
1.6 mm
0.033 in.
0.063 in.
6 mm
9.7 mm
0.236 in.
0.382 in.
straight M12
Electrical characteristics
48 V AC / 60 V DC
min. 100 MOhm
Mechanical data
screwable
10 N
min. 100
Materials and material properties
GD-Zn (zinc die-cast)
CuZnPb (brass)
Ni + Au (nickel-gold)
CuSn (tin bronze)
Sn (tin)
PA UL94-V0
Ni (nickel)
compliant
Environmental conditions
-40 °C
85 °C
-40 °F
185 °F
II
3
Check US distributor inventory
Part number
MMF881A115
4251394625249
