M12 Panel feed through adapters, D-coded,
to RJ45 - straight
Description
- panel feed-through adapter M12 to RJ45 for control cabinets
- M12 jack D-coded, IP67, per IEC/PS 61076-2-101
- RJ45 jack, IP20, per IEC 60603-7-51
- for 100 MBit Fast Ethernet (IEEE 802.3an)
- Cat.5
- plug-in direction: straight
- solid zinc die-cast housing, nickel-plated
- suitable for applications in the railway industry according to data sheet
Technical Data
General Data
Jack
back side
shielded
Copper
metallike
46.35 mm
21.6 mm
29 mm
1.825 in.
0.85 in.
1.142 in.
on housing
Transmission characteristics
5
5
Connections/interfaces
RJ45-jack
M12-jack
D-coded
1
1
8P/4C
4
Electrical characteristics
0.5 A
60 V DC
Materials and material properties
GD-Zn (zinc die-cast)
yes
compliant
Environmental conditions
IP2X
IPX0
IP6X when plugged in
IPX7 when plugged in
2
Check US distributor inventory
Part number
MWN811A115
4251394609836
Downloads
- Brochure (Feed-through adapters M12 X- and D-coded to RJ45 for electrical cabinets)
- Brochure (Overview M12)
- 3D-Data - Registration required -
- Mounting note
- Data sheet
