E-DAT Industry RJ45 field plug insert Cat.5 Class D PROFINET

Description
  • Cat.5 plug to be assembled in the field and mounted in IP67 plug housings of variants 1, 4, 5 and 14
  • 100 MBit suitable according to IEEE 802.3
  • suitable for Remote Powering (PoE, PoE plus and UPoE) and HDBaseT
  • 4-wire RJ45 plug for AWG 22 to be assembled in the field
  • connection of AWG 26/7 - 22/7, AWG 26/1 - 22/1 possible
  • solid copper wire diameter from 0.4 to 0.64 mm
  • stranded copper wire diameter from 0.48 to 0.76 mm
  • conductor diameter up to 1.6 mm
  • cable jacket from 5.5 to 8.5 mm
  • consists of only 2 parts
  • easy assembly - connection without special tools
  • zinc die-cast housing for industrial use
  • protected locking hook
  • can be used as test plug at IP67 end of variants 1, 4, 5, 6 and 14
Check US distributor inventory
Part number
1401400810PI
4250184180333
