Cat.7 cable connector

Description
  • for connecting/extending data cables up to Cat.7A
  • class EA to ISO/IEC 11801 Ed.2.2:2011-06 is complied with in combination with Cat.6, Cat.6A, Cat.7 and Cat.7A cables and Cat.6 connectors
  • connection of data lines AWG 26/1 to 22/1 (solid wire)
  • cable feed from one or two sides
  • cable sharing, i.e. splitting one 8-wire cable into two 4-wire cables (one cable tie required each on input and output side)
  • fully shielded metal housing
  • strain relief and separate captive 360° shield connection
  • 2 bore holes for wall mounting
  • IP67 protection due to special shrink tube
Technical Data
General Data
M1
I1
C1
E2
cable connector
shielded
Copper
metallike
114.2 mm
20.5 mm
36.9 mm
4.496 in.
0.807 in.
1.453 in.
Transmission characteristics
7
EA
Connections/interfaces
LSA terminal block
LSA terminal block
1
1
1
1
AWG 26/1 - AWG 22/1
0,128 - 0,324 mm²
0,409 - 0,643 mm
0,016 - 0,025 in.
5.5 mm
9,6
0.197 in.
0.354
from one or two sides
yes, if cross section is greater or the same
Electrical characteristics
60 V
max. 5 mOhm
min. 100 MOhm
750 V DC
Mechanical data
min. 100
Materials and material properties
GD-Zn (zinc die-cast)
yes
no paint wetting interfering substances (LaBS) in the process chain
subsequent contamination possible due to handling and possible storage in your company
compliant
Environmental conditions
-25 °C
85 °C
-13 °F
185 °F
-25 °C
85 °C
-13 °F
185 °F
490 m/s²
