EIW-C18 230 V AC

Description

Monitoring of direct or alternating currents in live systems. It is displayed whether the adjusted values are exceeded or not reached, and a switching process is triggered. The integrated 7-segment display indicates the sources of the fault. The current to be measured (AC or DC), an upper and a lower threshold value, a response delay and the fault memory (ON or OFF) can be adjusted manually on the device. The two current measuring ranges can be selected by means of the terminal blocks. Faults can be acknowledged directly on the device or by means of an external contact.

  • Connection with screw type terminal blocks
Technical Data
General Data
230 V AC, 50 Hz
max. 15 mA
0.01 A to 1 A
0.1 A to 15 A
0.1 s to 9.9 s, adjustable
2 x changeover contacts (DPDT)
max. 250 V AC
max. 8 A
3 x 107 switching cycles
1 x 105 switching cycles
2 x 7-segment displays
Green and red LED
50 x 69,3 x 60 mm
200 g
-5 °C to 55 °C
-20 °C to 70 °C
IP40 / IP20
Check US distributor inventory
Accessories
Part number
11027205
4250184120971
