The EWIO2-M is a powerful data logger for the energy consumption monitoring and energy monitoring in buildings, on machines, plants and systems. Two Ethernet ports with a Daisy Chain function are available for the chain further Data logger and connection to the LAN network. The system is parameterised, configured and commissioned through a platform-independent web browser. The M-Bus and Modbus RTU interfaces enable to read different meters: e.g. electricity, water, gas and heat. Optionally, the measured values can either be sent from the data base (push) or read out (pull) via mail (SSL) or FTP (SFTP). Simple functions and control tasks in building or industrial automation can be created and visualized via the graphic programming interface "Node-RED" integrated in the web interface and the numerous digital and analog I/Os. An integrated µSD memory card expands the range of functions of the EWIO2-M for save settings, data and applications.

Technical Data
General Data
24 V DC +/- 10%
550 mA
-5 °C to +55 °C
2 x RJ45 LAN 10/100BaseT (Daisy Chain)
NXP i.MX7D Dual Core, ARM-A7, 1 GHz, max. 32 GB / ext. 2 GB µSD
Linux embedded
Extension bus, max. 6 MR-I/O bus modules, Modbus RTU, max. 32 participants, M-Bus (DIN EN 13757-T1,2,3), max. 80 M-Bus charges
8x digital inputs, 3 x analog universal inputs, 8 x digital outputs, 3 x analog outputs
