PCB connection M12
The M12 connector is an industrial connector that is used at field level and in Industrial Ethernet. It is a circular connector with a metric thread that has been developed in several variants and codings for different degrees of protection.
Product Highlights
Overview
-
A-coded
-
D-coded
-
X-coded
-
protection class: IP67
-
mated state
-
unmated state
-
number of poles:
2, 3, 4, 5, 8 -
RoHS compliant
-
fully shielded
-
EMC-compliant
- electrically sensitive environment
- machines & systems
- robotics
- measurement technology
- process monitoring
- camera systems
-
robust & reliable
-
space-saving
-
high degree of protection
-
high mechanical robustness against vibrations
-
noise immunity
